Product Detailed Parameters
- Description：FILTER LC(PI) 5000PF CHASSISSIS
- Series：-
- Mfr：Tusonix a Subsidiary of CTS Electronic Components
- Package：Bulk
- Type：Low Pass
- Filter Order：3rd
- Technology：LC (Pi)
- Number of Channels：1
- Center / Cutoff Frequency：-
- Attenuation Value：65dB @ 100MHz
- Resistance - Channel (Ohms)：-
- Values：C = 5000pF
- ESD Protection：No
- Operating Temperature：-55°C ~ 125°C
- Applications：-
- Voltage - Rated：100V
- Mounting Type：Chassis Mount
- Package / Case：Axial, Bushing, 1 Turret Lead
- Size / Dimension：0.250" Dia x 0.468" L (6.35mm x 11.89mm)
- Height：-
- Current：10:00 AM
Download product information
Overview
The M15733/61-0010 is an EMI feedthrough filter manufactured by Tusonix, a subsidiary of CTS Electronic Components. It belongs to the 4203 series and utilizes a PI circuit topology for noise suppression. The component features a capacitance of 5500pF and is rated for 100V at 125°C. It supports a current capacity of 10A and employs UNF-2A threading for mounting.
Feature Summary
- Provides electromagnetic interference suppression through a dedicated PI filter circuit design
- Utilizes threaded mounting interface for secure panel installation
- Engineered for high-voltage and high-current signal line protection
Applications
- Military and aerospace electronic systems requiring MIL-spec filtering
- High-reliability communication equipment signal lines
- Industrial control panels with sensitive electronics
Procurement Notes
Verify that the specific order matches the M15733/61-0010 designation rather than similar series numbers like 4253-500 or 4101-502. Confirm RoHS compliance status as indicated in official documentation, noting potential variations. Ensure the UNF-2A thread specification aligns with existing panel cutouts before procurement.
Selection Notes
Select this component when a 5500pF capacitance value is required for EMI attenuation in 100V applications. The 10A current rating dictates suitability for power or high-current signal paths. Verify that the physical dimensions and UNF-2A mounting style fit the mechanical constraints of the target enclosure.
Part Context
This part is part of the M15733/61 family of feedthrough filters produced by Tusonix/CTS. It shares design lineage with related parts such as M15733/61-0011 and M15733/61-0012, which may offer different capacitance values within the same series. The product falls under the broader category of EMI/RFI filters used in critical infrastructure.
Replacement Considerations
Cross-reference tools indicate parametrically similar parts within the Tusonix portfolio. Verify exact capacitance and voltage ratings against substitutes like those in the 4203 series to ensure functional equivalence without altering system performance.
