M15733/66-0001

Overview

The M15733/66-0001 is a custom EMI feedthrough filter manufactured by Tusonix, a subsidiary of CTS. Classified as an LC Pi filter, it features a capacitance of 1750 pF and a voltage rating of 200 V. The component supports a maximum DC current of 10 A. It utilizes a threaded interface for mounting and is designed to suppress electromagnetic interference in electronic circuits.

Feature Summary

• Provides effective suppression of unwanted electromagnetic interference signals within connected systems.
• Utilizes an LC Pi filter topology to attenuate noise across the signal path.
• Features a threaded mechanical design suitable for secure panel or chassis mounting.

Applications

• Electronic equipment requiring EMI suppression
• Power supply input filtering applications
• Signal line noise reduction in sensitive electronics

Procurement Notes

Verify the specific capacitance and voltage ratings against the project requirements before procurement. Confirm that the custom nature of this part aligns with the manufacturing timeline. Ensure the threaded interface specifications match the mounting hardware available in the assembly. Check for any specific handling instructions regarding the ceramic construction.

Selection Notes

Select this component when a custom LC Pi filter configuration is required for EMI suppression. Consider the 1750 pF capacitance and 200 V rating for compatibility with the circuit's electrical parameters. Evaluate the 10 A current capacity to ensure it meets the load requirements. Verify the threaded interface dimensions for proper mechanical integration.

Part Context

This component belongs to the M15733 series of EMI feedthrough filters produced by Tusonix. These filters are designed for high-performance noise suppression in various electronic applications. The series offers different configurations to meet specific filtering needs, with this model representing a custom LC Pi variant.

Replacement Considerations

Consult the manufacturer's cross-reference tools for parametrically similar parts. Verify that any substitute matches the 1750 pF capacitance, 200 V rating, and 10 A current capacity. Ensure the replacement maintains the same threaded interface and LC Pi filter topology for functional equivalence.
