M20-7830646

Overview

The M20-7830646 is a 12-position female socket header from the Harwin M20 series, designed for through-hole PCB mounting. It features a 2.54 mm (0.1 in) pitch and a single row configuration. The connector utilizes tin-plated contacts with a current rating of 3A and a voltage rating of 1000V. The housing is constructed from polyamide insulation material, ensuring durability and electrical stability.

Feature Summary

• Through-hole solder termination for secure PCB attachment
• Polyamide insulation material for thermal and electrical stability
• Tin-plated contacts to ensure reliable signal transmission

Applications

• Industrial factory equipment
• Data collection systems
• Mobile maintenance units
• Display control systems
• Portable test equipment

Procurement Notes

Verify component authenticity by cross-referencing the manufacturer part number with official Harwin documentation. Confirm that the specific tin plating and polyamide housing match the technical requirements for your application environment. Ensure compatibility with mating pin headers before finalizing procurement decisions.

Selection Notes

Select this component when a 12-position female receptacle is required for high-voltage applications up to 1000V. The 3A current rating and through-hole design make it suitable for robust industrial connections where standard board-to-board interfaces are insufficient.

Part Context

This component belongs to the M20 series, which provides compact interconnect solutions for space-constrained designs. The series offers various configurations including single and double rows with different contact counts, all sharing the standardized 2.54 mm pitch for broad industry compatibility.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult Harwin directly for potential obsolescence management or alternative series recommendations if this specific 12-position variant is discontinued.
