Product Detailed Parameters
- Description：CONN RCPT 6POS 0.1 GOLD PCB R/A
- Series：M20
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Receptacle
- Contact Type：Female Socket
- Style：Board to Board or Cable
- Number of Positions：6
- Number of Positions Loaded：All
- Pitch - Mating：0.100" (2.54mm)
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：-
- Insulation Color：Black
- Insulation Height：0.232" (5.90mm)
- Contact Length - Post：0.118" (3.00mm)
- Operating Temperature：-40°C ~ 105°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：Tin
- Mated Stacking Heights：-
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：3A
- Voltage Rating：1000V
Download product information
Overview
The M20-7880342 is a rectangular socket assembly connector from the Harwin M20 series. It features a 6-position configuration with a 2.54 mm (0.1 in) pitch across two rows. Designed for surface mount installation, it utilizes phosphor bronze contacts with gold plating on the mating interface and tin plating on the tail. The unit operates within a temperature range of -40°C to +105°C and meets UL94 V-0 flammability standards.
Feature Summary
- Surface mount design for automated PCB assembly
- Gold-plated contacts ensure reliable signal transmission
- Dual-row configuration maximizes connection density
- High-temperature resistant polyamide insulation
Applications
- Board-to-board interconnections
- Industrial control systems
- Telecommunications equipment
Procurement Notes
Verify component authenticity through authorized channels. Confirm that the specific suffix matches the required contact plating and orientation specifications. Ensure storage conditions maintain integrity prior to soldering. Check for RoHS compliance documentation if required by project regulations.
Selection Notes
Select this component when a low-profile, dual-row SMT receptacle is required. The 2.54 mm pitch suits standard board layouts. Gold plating is preferred for corrosion resistance. Verify stack height requirements against mating header dimensions before finalizing the design.
Part Context
This part belongs to the M20 series, known for high-density interconnects. It serves as a counterpart to male headers in board-to-board applications. The series supports various pin counts and mounting styles for diverse electronic packaging needs.
Replacement Considerations
M20-7880642
FAQ
What is the contact material?
The contacts are made of phosphor bronze.
Is the connector polarized?
The datasheet does not specify keying or polarization features for this specific part number.
