M20-7880546

Overview

The M20-7880546 is a 10-position female receptacle connector from the Harwin M20 series, designed for right-angle through-hole PCB mounting. It features a 2.54 mm (0.100 inch) pin-to-pin spacing and utilizes tin-plated contacts. The connector is configured as a single row with a straight housing orientation relative to the board edge, facilitating compact vertical integration in dense circuit layouts.

Feature Summary

• Right-angle through-hole termination for space-efficient vertical board stacking
• Single-row configuration with 2.54 mm pitch for standard interconnect compatibility
• Tin-plated brass contacts ensuring reliable signal transmission

Applications

• Vertical board-to-board interconnections
• High-density PCB assembly requiring right-angle routing
• Industrial control modules with limited lateral space

Procurement Notes

Verify the specific suffix against the manufacturer datasheet to confirm right-angle orientation and plating specifications. Ensure the ordering part number matches the exact contact count and termination style required for the target PCB footprint. Cross-reference with official Harwin documentation to validate compliance with current RoHS standards before final procurement.

Selection Notes

Select this component when a right-angle female header is required for through-hole assembly. The 2.54 mm pitch ensures compatibility with standard male pins. Consider the mechanical height constraints of the right-angle design compared to straight headers to ensure adequate clearance within the enclosure or adjacent components.

Part Context

This component belongs to the Harwin M20 series, a line of industrial-grade connectors known for durability and high reliability. The M20 series supports various configurations including straight and right-angle headers, catering to diverse PCB layout requirements in demanding electronic environments.

Replacement Considerations

M20-7880546-DG
