Product Detailed Parameters
- Description：CONN RCPT 20POS 0.1 TIN PCB R/A
- Series：M20
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Receptacle
- Contact Type：Female Socket
- Style：Board to Board or Cable
- Number of Positions：20
- Number of Positions Loaded：All
- Pitch - Mating：0.100" (2.54mm)
- Number of Rows：1
- Row Spacing - Mating：-
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Finish - Mating：Tin
- Contact Finish Thickness - Mating：100.0µin (2.54µm)
- Insulation Color：Black
- Insulation Height：0.130" (3.30mm)
- Contact Length - Post：0.118" (3.00mm)
- Operating Temperature：-40°C ~ 105°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：Tin
- Mated Stacking Heights：-
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：3A
- Voltage Rating：1000V
Download product information
Overview
The Harwin M20-7892046 is a 20-position female socket assembly from the M20 series. It features a single row configuration with a 2.54 mm (0.1 in) pitch. The connector utilizes through-hole mounting with right-angle termination for PCB integration. The unit weighs 1.818 g and complies with RoHS standards.
Feature Summary
- Single-row horizontal receptacle design
- Right-angle through-hole solder termination
- Compact form factor for space-constrained layouts
Applications
- Board-to-board interconnects
- Limited space electronic assemblies
- General purpose PCB headers
Procurement Notes
Verify component authenticity through authorized channels due to potential market variations. Confirm that the specific part number matches the required single-row, right-angle specification. Ensure compatibility with existing PCB footprint designs before procurement. Validate compliance documentation against current regulatory requirements.
Selection Notes
Select this component when a single-row, right-angle female header is required. The 2.54 mm pitch ensures standard mating compatibility. Consider the through-hole mounting method for robust mechanical stability. Evaluate the compact profile against available board real estate constraints.
Part Context
This component belongs to the Harwin M20 series of headers and wire housings. The series provides various configurations for board-to-board connections. The M20-7892046 specifically addresses needs for horizontal, single-row interfaces.
Replacement Considerations
No public confirmed substitute part numbers are available.
