Product Detailed Parameters
- Description：CONN RCPT 6POS 0.1 GOLD SMD R/A
- Series：M20
- Mfr：Harwin Inc.
- Package：Tape & Reel (TR),Cut Tape (CT)
- Connector Type：Receptacle
- Contact Type：Forked
- Style：Board to Board
- Number of Positions：6
- Number of Positions Loaded：All
- Pitch - Mating：0.100" (2.54mm)
- Number of Rows：1
- Row Spacing - Mating：-
- Mounting Type：Surface Mount, Right Angle
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：0.59µin (0.015µm)
- Insulation Color：Black
- Insulation Height：0.098" (2.50mm)
- Contact Length - Post：-
- Operating Temperature：-40°C ~ 105°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：Tin
- Mated Stacking Heights：-
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：3A
- Voltage Rating：-
Download product information
Overview
The M20-7910642R is a surface-mount board-to-board receptacle from the Harwin M20 series. It features a single row of six contacts with a 2.54 mm (0.1 inch) pitch. The connector utilizes right-angle orientation for vertical mating and employs gold plating on contact surfaces to ensure reliable signal transmission. Designed for SMT assembly, it supports horizontal mounting configurations.
Feature Summary
- Surface-mount technology compatible design for automated PCB assembly
- Right-angle receptacle configuration enabling vertical board interconnection
- Gold-plated contact surfaces for enhanced conductivity and corrosion resistance
Applications
- Board-to-board interconnections in compact electronic modules
- High-density circuit board stacking applications
- Industrial control systems requiring reliable surface-mount headers
Procurement Notes
Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status and specific packaging requirements prior to order placement. Ensure storage conditions align with moisture sensitivity level specifications to maintain solderability and performance integrity during assembly processes.
Selection Notes
Select this component when a low-profile, right-angle board-to-board connection is required. The 2.54 mm pitch suits standard spacing layouts. Verify that the receiving header matches the 6-pin count and single-row configuration. Consider the right-angle form factor for space-constrained vertical stacking scenarios within the M20 ecosystem.
Part Context
This part belongs to the Harwin M20 series, which specializes in 2.54 mm pitch connectors. The M20 range includes various header and socket options for both through-hole and surface-mount technologies. This specific model represents a right-angle receptacle variant designed for robust board-to-board connectivity in modern electronics manufacturing.
Replacement Considerations
Compatible substitutes within the M20 series include other 6-pin right-angle SMT receptacles such as M20-7862342 variants, provided pin count and pitch match. Cross-series replacements require verification of mechanical dimensions and electrical ratings against original design specifications.
