M20-8750542

Overview

The M20-8750542 is a male pin header from the Harwin M20 series, designed for surface mount board-to-board and wire-to-board connections. It features a single row of ten contacts with a 2.54 mm pitch. The connector utilizes brass contacts with gold plating and a nylon housing. Rated for 3A current and 250V voltage, it operates within a temperature range of -40°C to +105°C. The straight orientation and solder termination ensure reliable PCB integration.

Feature Summary

• Surface mount design for automated assembly
• Gold-plated brass contacts for corrosion resistance
• Nylon housing for electrical insulation
• Straight orientation for compact layouts

Applications

• Board-to-board interconnects
• Wire-to-board connections
• General electronic equipment
• Industrial control systems

Procurement Notes

Verify the specific contact count and row configuration against project requirements before ordering. Confirm that the surface mount footprint matches the PCB design. Check for any RoHS compliance documentation if required by the application. Ensure the operating temperature range meets environmental specifications. Validate compatibility with mating connectors in the system.

Selection Notes

Choose this component for applications requiring high-density surface mount headers. The 2.54 mm pitch offers standard spacing for widespread compatibility. Gold plating ensures durability in harsh environments. Consider the 3A rating for power distribution needs. Evaluate the straight profile for space-constrained designs.

Part Context

Part of the M20 series, known for robust performance in demanding environments. The series offers various configurations for different connection needs. Harwin focuses on reliability and precision in connector manufacturing. This model represents a standard solution for general-purpose interconnects.

Replacement Considerations

No public confirmed substitute part numbers are available.
