Product Detailed Parameters
- Description：CONN HEADER SMD 12POS 2.54MM
- Series：M20
- Mfr：Harwin Inc.
- Package：Bulk
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：12
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Surface Mount
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.228" (5.80mm)
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.100" (2.54mm)
- Contact Shape：Square
- Contact Finish - Mating：Tin
- Contact Finish Thickness - Mating：-
- Contact Finish - Post：Tin
- Contact Material：Brass
- Insulation Material：Polyamide (PA6T), Nylon 6T
- Features：-
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A per Contact
- Voltage Rating：250V
Download product information
Overview
The M20-8760646 is a surface mount pin header from the Harwin M20 series, designed for board-to-board and wire-to-board interconnections. It features a dual in-line configuration with 12 positions arranged in two rows of six contacts each. The connector utilizes a 2.54 mm pitch and employs gold-plated brass contacts for reliable signal transmission. Solder termination ensures secure PCB attachment. The housing is constructed from nylon, providing structural integrity and electrical insulation.
Feature Summary
- Dual row surface mount design for compact circuit board integration
- Gold-plated brass contacts ensure durable and low-resistance connections
- Nylon housing provides robust mechanical support and insulation
Applications
- Board-to-board interconnect systems
- Wire-to-board assembly applications
- General electronic device signal routing
Procurement Notes
Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status and specific lot codes upon order placement. Ensure storage conditions maintain material integrity prior to soldering processes. Cross-reference datasheet specifications against current manufacturing revisions to guarantee compatibility with existing design parameters.
Selection Notes
Select this component when a 12-position dual row surface mount header is required. Verify that the 2.54 mm pitch matches the target footprint. Confirm that the operating temperature range of -40°C to 105°C suits the application environment. Ensure the mating connector aligns with the male pin configuration and compatible contact plating requirements.
Part Context
This part belongs to the Harwin M20 series, which offers various configurations for high-density interconnect needs. The series supports both single and dual row arrangements with different position counts. It is engineered for reliability in demanding electronic environments, providing consistent performance across diverse industrial and commercial applications.
