M20-8770546

$0.31

Description：CONN HEADER SMD 5POS 2.54MM
Series：M20
Mfr：Harwin Inc.
Package：Bulk

SKU:67ad48232ae3 Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M20-8770546 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is CONN HEADER SMD 5POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for M20-8770546

Description：CONN HEADER SMD 5POS 2.54MM
Series：M20
Mfr：Harwin Inc.
Package：Bulk
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：5
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.228" (5.80mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.100" (2.54mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：-
Contact Finish - Post：Tin
Contact Material：Brass
Insulation Material：Polyamide (PA6T), Nylon 6T
Features：-
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for M20-8770546

M20-8770546

Headers, Male Pins Overview

Harwin M20-8770546 is a vertical surface mount pin header from the M20 series. It features a 2.54 mm (0.100 inch) pitch with 10 positions arranged in a single row. The connector utilizes brass contacts with gold plating for reliable signal transmission. Designed for board-to-board or wire-to-board applications, it supports a rated current of 3A per contact and operates within a temperature range of -40°C to +105°C. The housing is constructed from nylon without a cover.

Headers, Male Pins Feature Summary

Vertical surface mount design for compact PCB integration
Gold-plated brass contacts ensure durable electrical performance
Single-row configuration simplifies layout and mating

Headers, Male Pins Applications

Board-to-board interconnections
Wire-to-board connections
Industrial control systems
Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix against official Harwin documentation to confirm contact plating and orientation. Ensure compatibility with mating connectors regarding height and pitch. Confirm RoHS compliance status through the manufacturer's latest environmental declarations before final procurement.

Headers, Male Pins Selection Notes

Select this component when a low-profile, single-row vertical header is required for surface mounting. Consider the 3A current rating and 250V voltage limit for circuit requirements. Verify that the PCB footprint matches the specified 2.54 mm pitch dimensions for proper soldering and mechanical stability.

Headers, Male Pins Part Context

The M20-8770546 belongs to the Harwin M20 family of connectors, known for robust performance in industrial and commercial environments. This series offers various configurations including different row counts and plating options. The part represents a standard solution for high-density interconnect needs where space efficiency is critical.
