M20-8891045R is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is CONN HEADER SMD R/A 10POS 2.54MM. Review the specifications below when checking this part for your BOM.
Headers, Male Pins specifications for M20-8891045R
- Description：CONN HEADER SMD R/A 10POS 2.54MM
- Series：M20
- Mfr：Harwin Inc.
- Package：Tape & Reel (TR),Cut Tape (CT)
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：10
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Surface Mount, Right Angle
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.236" (6.00mm)
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.098" (2.50mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：Flash
- Contact Finish - Post：-
- Contact Material：Brass
- Insulation Material：Polyamide (PA9T), Nylon 9T, Glass Filled
- Features：-
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A per Contact
- Voltage Rating：-
Headers, Male Pins datasheet and documents for M20-8891045R
Headers, Male Pins Overview
The Harwin M20-8891045R is a surface mount pin header from the M20 series, designed for board-to-board and wire-to-board connections. It features a 2.54 mm pitch with 10 contacts arranged in a single row. The connector utilizes gold-plated brass contacts and a nylon housing, supporting a current rating of 3A and a voltage of 250V. Operating temperatures range from -40°C to +105°C, with a right-angle orientation suitable for compact PCB layouts.
Headers, Male Pins Feature Summary
- Right-angle surface mount design for space-constrained applications
- Gold-plated contacts ensure reliable signal transmission
- Compatible with standard SMT assembly processes
Headers, Male Pins Applications
- Board-to-board interconnections
- Wire-to-board connections
- Compact electronic device assemblies
Headers, Male Pins Procurement Notes
Verify the specific suffix 'R' indicates the right-angle configuration and surface mount variant. Confirm contact count and plating specifications against the official datasheet before integration. Ensure compatibility with automated pick-and-place equipment for surface mounting.
Headers, Male Pins Selection Notes
Select this component when right-angle surface mounting is required for low-current signal paths. The 2.54 mm pitch ensures compatibility with standard mating connectors. Verify thermal resistance during reflow soldering to maintain housing integrity within the specified temperature limits.
Headers, Male Pins Part Context
This part belongs to the Harwin M20 series, a family of industrial standard connectors known for high reliability. The series offers various configurations including through-hole and surface mount options, catering to diverse density and height constraints in modern electronics manufacturing.
Headers, Male Pins Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Cross-reference with other M20 series variants only if mechanical and electrical parameters match exactly.
