M20-9700246

Headers, Male Pins Overview

The Harwin M20-9700246 is a dual-in-line (DIL) horizontal pin header from the M20 series, designed for board-to-board and wire-to-board connections. It features a 2.54 mm pitch with two rows of contacts, totaling four positions. The connector utilizes a straight orientation and through-hole solder termination for secure PCB mounting. Constructed with a nylon housing and tin-plated brass contacts, it supports standard industrial operating temperatures ranging from -40°C to +105°C.

Headers, Male Pins Feature Summary

• Dual-in-line configuration providing compact multi-circuit connectivity
• Horizontal orientation facilitates low-profile board stacking applications
• Through-hole solder termination ensures robust mechanical fixation

Headers, Male Pins Applications

• Board-to-board interconnects in industrial control modules
• Wire-to-board connections for peripheral interface circuits
• General-purpose signal routing on dense PCB layouts

Headers, Male Pins Procurement Notes

Verify the specific contact plating finish and housing material grade against project requirements before ordering. Confirm that the horizontal orientation aligns with the mechanical assembly constraints of the target PCB design. Ensure compatibility with mating socket components within the same M20 series family to guarantee proper electrical engagement and dimensional fit.

Headers, Male Pins Selection Notes

Select this component when a low-profile horizontal connection is required for four-channel signal transmission. The 2.54 mm pitch offers broad compatibility with standard ribbon cables and mating headers. Consider the through-hole mounting method if high vibration resistance is necessary compared to surface-mount alternatives.

Headers, Male Pins Part Context

This part belongs to the Harwin M20 series, which provides 2.54 mm pitch connectors conforming to industry-standard pin header and socket systems. The series is engineered for high-density applications, offering various row counts and orientations to meet diverse PCB layout requirements while maintaining reliable electrical performance.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 2.54 mm pitch DIL horizontal pin headers with identical row and position counts. Verify that alternative parts match the current rating and temperature specifications. Ensure the mating socket geometry remains consistent to prevent assembly issues.
