M20-9700345

Headers, Male Pins Overview

The Harwin M20-9700345 is a 6-pin (2x3) male pin header from the M20 series, featuring a 2.54mm pitch. It utilizes twin beam contacts with selective gold and tin plating for reliable connectivity. Designed for through-hole mounting, it supports board-to-board and wire-to-board systems. The connector operates within a temperature range of -40°C to +105°C and is rated for 3A current at 500V. The housing is constructed from nylon, ensuring durability in industrial applications.

Headers, Male Pins Feature Summary

• Twin beam contact design ensures cost-effective reliability and secure mating
• Selective gold and tin plating provides corrosion resistance and low contact resistance
• Nylon housing offers mechanical stability and thermal endurance

Headers, Male Pins Applications

• Industrial control system interconnections
• Consumer electronics assembly
• Automotive electronic modules
• General-purpose PCB-to-PCB connections

Headers, Male Pins Procurement Notes

Verify the specific pin configuration and orientation against the official datasheet before integration. Ensure compatibility with mating female connectors from the same M20 series family. Confirm that the selected variant matches the required current and voltage ratings for the target application environment.

Headers, Male Pins Selection Notes

Select this component when a robust, high-current connection is required for through-hole PCBs. The twin beam technology distinguishes it from standard single-beam headers, offering improved retention force. Consider the operating temperature range and material specifications to ensure suitability for harsh environments or high-density layouts.

Headers, Male Pins Part Context

This part belongs to the M20 series, which represents industry-standard 2.54mm pitch connectors. The series is widely recognized for its versatility in various electronic assemblies. The M20-9700345 specifically addresses the need for a horizontal, double-row configuration with enhanced contact performance.

Headers, Male Pins Replacement Considerations

Compatible mating parts include female sockets from the M20 series. Verify pin count and pitch alignment when substituting. No direct cross-model substitutes are confirmed without verifying mechanical footprint compatibility.
