M20-9703346

Headers, Male Pins Overview

The Harwin M20-9703346 is a male pin header from the M20 series, featuring a 2.54 mm pitch and 66 positions in a single row configuration. Designed for right-angle through-hole mounting, it utilizes a black nylon housing and tin-plated brass contacts. The component supports a current rating of 3 A and a voltage rating of 750 V, operating within a temperature range of -40°C to 105°C.

Headers, Male Pins Feature Summary

• Right-angle PCB mounting orientation for space-efficient board layouts
• Tin-plated brass contacts ensure reliable electrical conductivity
• Black nylon insulation provides durable structural support

Headers, Male Pins Applications

• Industrial control systems requiring high-density connections
• Medical equipment with critical electronic interfaces
• Metering and measurement instrumentation

Headers, Male Pins Procurement Notes

Verify the specific part number against official Harwin documentation to confirm availability status, as this item may be subject to end-of-life or discontinuation notices. Ensure compatibility with mating connectors before procurement. Cross-reference datasheets for precise mechanical dimensions and plating specifications to avoid substitution errors.

Headers, Male Pins Selection Notes

Select this connector when a high-count, right-angle male header is required for through-hole assembly. The 66-position count accommodates complex signal routing. Verify that the 750 V rating and 3 A current capacity meet circuit requirements. Confirm that the 2.54 mm pitch aligns with existing PCB footprint designs and mating socket specifications.

Headers, Male Pins Part Context

This component belongs to the Harwin M20 series, which offers versatile pin headers for various applications. The series includes both vertical and right-angle configurations with multiple row options. The M20-9703346 specifically addresses needs for dense, angled interconnections using standard 2.54 mm spacing.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided data. Consult Harwin technical support for direct replacements or compatible alternatives within the M20 series.
