M20-9710245

Headers, Male Pins Overview

The M20-9710245 is a single-row pin header assembly from the Harwin M20 series, designed for through-hole mounting. It features a 2.54 mm pitch and contains 39 positions. The connector utilizes brass contacts with gold plating and a black nylon housing. Rated for 3 A current and 750 V voltage, it operates within a temperature range of -55°C to +105°C. The component has a right-angle orientation and is RoHS compliant.

Headers, Male Pins Feature Summary

• Gold-plated brass contacts ensure reliable electrical performance
• Nylon housing provides thermal stability up to 105°C
• Right-angle design facilitates compact board layout integration

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• General electronic equipment signal routing

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official Harwin documentation to confirm contact plating, row count, and position quantity. Ensure the right-angle orientation matches the target PCB footprint requirements. Confirm RoHS compliance status via the manufacturer datasheet before finalizing procurement specifications.

Headers, Male Pins Selection Notes

Select this component when a high-density single-row connection is required in a constrained vertical space. The right-angle configuration allows for perpendicular mating interfaces. Verify that the 39-position count aligns with circuit signal requirements and that the 2.54 mm pitch matches existing system standards.

Headers, Male Pins Part Context

This part belongs to the M20 series, a widely used connector family known for robust mechanical performance. The M20-9710245 specifically addresses applications requiring horizontal pin headers with extended tail lengths for secure soldering. It complements other M20 variants offering different orientations and contact counts.

Headers, Male Pins Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Cross-reference with other M20 series single-row headers if identical specifications are unavailable.
