M20-9710545

Headers, Male Pins Overview

The Harwin M20-9710545 is a single-row pin header from the M20 series, featuring a 2.54 mm pitch and five positions. It utilizes gold-plated brass contacts with a nylon housing for board-to-board or cable connections. Designed for through-hole mounting, this straight connector supports a current rating of 3 A and operates within a temperature range of -40°C to +105°C.

Headers, Male Pins Feature Summary

• Gold-plated contacts ensure reliable signal transmission and corrosion resistance.
• Nylon housing provides mechanical stability and electrical insulation.
• Through-hole solder termination offers secure PCB attachment.

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board assemblies
• General electronic circuit prototyping

Headers, Male Pins Procurement Notes

Verify the specific part number against official Harwin documentation to confirm availability and compliance status. Ensure that the selected component matches the required pitch, row count, and contact plating specifications for your design. Cross-reference datasheets for accurate mechanical dimensions and thermal ratings before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a low-profile, single-row connection is required. The 2.54 mm pitch ensures compatibility with standard breadboard and PCB layouts. Consider the 3 A current rating and operating temperature limits to ensure suitability for the intended electrical load and environmental conditions.

Headers, Male Pins Part Context

This component belongs to the Harwin M20 series, known for high-density connectivity solutions. The M20-9710545 specifically addresses applications needing a compact, five-position interface. Its design aligns with industry-standard spacing, facilitating integration into various electronic systems requiring robust and space-efficient connections.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided data. Consult official Harwin resources for potential alternatives or updated product lines if this specific variant is discontinued or unavailable.
