M20-9720246

Headers, Male Pins Overview

The Harwin M20-9720246 is a single row, straight pin header from the M20 series. It features a 2.54 mm pitch and two positions. The connector utilizes brass contacts with tin plating and a nylon housing. Rated for 3 A current and 750 V voltage, it supports through-hole mounting. Designed for board-to-board and wire-to-board applications, it operates within a temperature range of -40°C to +105°C.

Headers, Male Pins Feature Summary

• Provides reliable electrical interconnection via tin-plated brass contacts housed in nylon.
• Supports direct vertical through-hole soldering for secure PCB attachment.

Headers, Male Pins Applications

• Board-to-board signal transmission
• Wire-to-board connections
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify the specific part number against official Harwin documentation to confirm availability status. Check for any recent lifecycle changes or obsolescence notices directly from the manufacturer before finalizing procurement plans.

Headers, Male Pins Selection Notes

Select this component when a low-profile, single-row header is required for standard 2.54 mm spacing applications. Ensure the design accommodates the specified 3 A current rating and 750 V insulation requirements for the target environment.

Headers, Male Pins Part Context

This component belongs to the M20 series, a line of connectors designed for general electronic interconnect needs. The series offers various configurations in terms of row count, position numbers, and contact materials to suit diverse assembly requirements.

Headers, Male Pins Replacement Considerations

Consult official Harwin resources for confirmed substitute part numbers. Do not assume cross-compatibility with other manufacturers' products without verifying mechanical and electrical specifications.
