M20-9720546

Headers, Male Pins Overview

The M20-9720546 is a vertical pin header connector from the Harwin M20 series, designed for through-hole mounting on printed circuit boards. It features a single row with ten positions and a standard 2.54mm (0.1 inch) pitch. The connector utilizes brass contacts with tin plating to ensure reliable signal transmission. Rated for 3A per contact, it supports board-to-board or cable-to-board applications within an operating temperature range of -40°C to +105°C.

Headers, Male Pins Feature Summary

• Vertical orientation facilitates compact board stacking and space-efficient layouts.
• Single-row configuration simplifies routing and reduces assembly complexity.
• Through-hole termination provides robust mechanical stability for high-vibration environments.

Headers, Male Pins Applications

• General-purpose electronic assemblies requiring reliable interconnects
• Industrial control systems with moderate current demands
• Consumer electronics utilizing standard 2.54mm spacing

Headers, Male Pins Procurement Notes

Verify the specific part number against official Harwin documentation to confirm active status and compliance with RoHS directives. Ensure that the tin-plated contacts meet the environmental requirements for your specific application. Cross-reference the datasheet for accurate mechanical dimensions before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a single-row, vertical header is required for through-hole PCB integration. The 2.54mm pitch is compatible with standard ribbon cables and mating headers. Consider the 3A current rating and thermal limits to ensure suitability for the intended electrical load and operating environment.

Headers, Male Pins Part Context

This component belongs to the M20 series, a widely used line of rectangular connectors known for their versatility and reliability. The M20 series offers various configurations, including different row counts and orientations, catering to diverse connectivity needs in modern electronics manufacturing.

Headers, Male Pins Replacement Considerations

Direct substitutes may include other M20 series variants with identical pitch and row count but different lengths or plating options. Verify mechanical compatibility and electrical ratings before replacing with alternative manufacturers' products.
