M20-9720745

Headers, Male Pins Overview

The M20-9720745 is a male pin header connector from the Harwin M20 series, designed for through-hole mounting. It features a single row with 14 positions and a 0.100 inch (2.54mm) pitch. The connector utilizes brass contacts with gold plating for reliable signal transmission. Insulated by black polyamide (PA6T), it supports a current rating of 3A per contact and operates within a temperature range of -40°C to +105°C. The unit is UL94 V-0 rated for flammability.

Headers, Male Pins Feature Summary

• Through-hole vertical pin strip design
• Gold-plated brass contacts for conductivity
• Polyamide insulation with UL94 V-0 rating

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• General electronic circuit assembly

Headers, Male Pins Procurement Notes

Verify the specific part number against official Harwin documentation to confirm availability status and lead times. Ensure compatibility with mating connectors regarding pitch and row configuration. Check for RoHS compliance requirements relevant to your manufacturing standards before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a single-row, 14-position header is required for PCB integration. Consider the 2.54mm pitch for standard spacing needs. Evaluate the 3A current rating and operating temperature range against system thermal and electrical loads. Confirm that through-hole soldering processes align with production capabilities.

Headers, Male Pins Part Context

This component belongs to the M20 series of rectangular connectors manufactured by Harwin Inc. The series offers various configurations in terms of position count and row arrangement. The M20-9720745 specifically addresses applications requiring a single-row male header with robust mechanical and electrical properties for stable connectivity.

Headers, Male Pins Replacement Considerations

Consult official Harwin resources for confirmed substitute part numbers. Verify dimensional compatibility and electrical specifications if considering alternative manufacturers. Ensure any replacement maintains the same pitch, contact material, and insulation ratings.
