M20-9730946

$0.33

Description：CONN HEADER VERT 9POS 2.54MM
Series：M20
Mfr：Harwin Inc.
Package：Bulk

SKU:82aa594ee000 Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M20-9730946 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is CONN HEADER VERT 9POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for M20-9730946

Description：CONN HEADER VERT 9POS 2.54MM
Series：M20
Mfr：Harwin Inc.
Package：Bulk
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：9
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.276" (7.00mm)
Contact Length - Post：0.122" (3.10mm)
Overall Contact Length：0.496" (12.60mm)
Insulation Height：0.100" (2.54mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：-
Contact Finish - Post：Tin
Contact Material：Brass
Insulation Material：Polyamide (PA6T), Nylon 6T
Features：-
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for M20-9730946

M20-9730946

Headers, Male Pins Overview

The M20-9730946 is a single-row, vertical pin header from the Harwin M20 series. It features a 2.54 mm pitch and provides 9 positions for board-to-board or wire-to-board connections. The connector utilizes brass contacts with tin plating and a nylon housing. It supports through-hole termination and operates within a temperature range of -40°C to +105°C. Rated for 3A current and 750V voltage, it offers reliable electrical performance in standard electronic assemblies.

Headers, Male Pins Feature Summary

Vertical orientation facilitates compact board stacking
Tin-plated brass contacts ensure corrosion resistance
Nylon housing provides mechanical stability

Headers, Male Pins Applications

General purpose PCB interconnects
Board-to-board signal transmission
Wire-to-board power distribution

Headers, Male Pins Procurement Notes

Verify the specific part number against official Harwin documentation to confirm availability status. Check for any end-of-life notices or obsolescence warnings associated with this component before finalizing procurement plans. Ensure compatibility with mating connectors regarding pin count and pitch.

Headers, Male Pins Selection Notes

Select this component when a single-row, vertical configuration is required for space-constrained designs. Confirm that the 2.54 mm pitch matches the target PCB footprint. Verify that the 3A current rating and 750V insulation voltage meet the system's electrical requirements.

Headers, Male Pins Part Context

This component belongs to the M20 series, which offers versatile through-hole and SMT options. The series includes various row counts and orientations, providing a standardized solution for diverse connectivity needs across industrial and consumer electronics applications.
