M20-9760242

Headers, Male Pins Overview

The M20-9760242 is a male pin header connector from the Harwin M20 series, designed for through-hole mounting. It features a single row with four positions and a 0.100-inch (2.54mm) pitch. The connector utilizes brass contacts with gold plating for reliable signal transmission. Rated for 3A current and 250V voltage, it operates within a temperature range of -40°C to 105°C. The housing is constructed from black nylon, ensuring UL94 V-0 flammability rating. This component supports board-to-board or cable connections, offering a robust solution for electronic interconnect applications requiring high reliability.

Headers, Male Pins Feature Summary

• Through-hole mounting style for secure PCB attachment
• Gold-plated brass contacts for enhanced conductivity
• Nylon insulation with UL94 V-0 fire rating
• Single-row configuration for compact design

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• General electronic equipment headers
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify the specific contact count and row configuration against the datasheet to ensure compatibility with the target PCB footprint. Confirm that the through-hole termination method aligns with the assembly process capabilities. Check for any RoHS compliance documentation if required by the end-product regulations. Ensure the operating temperature range meets the environmental conditions of the final application.

Headers, Male Pins Selection Notes

Select this model when a low-profile, single-row header is required for through-hole assembly. The 2.54mm pitch is standard for general-purpose interconnects. Consider the 3A current rating for power distribution needs. The gold plating offers superior corrosion resistance compared to tin-only options. Evaluate the mechanical stability provided by the through-hole pins versus surface-mount alternatives.

Headers, Male Pins Part Context

This part belongs to the Harwin M20 series, known for its high-reliability connectors in demanding environments. The M20 series offers various configurations including single and double rows with different pin counts. The M20-9760242 specifically addresses the need for a small, four-position vertical header. It complements other M20 variants that offer higher pin counts or different mounting styles.

Headers, Male Pins FAQ

What is the rated voltage for the M20-9760242?

The rated voltage is 250V.

Is the connector suitable for high-temperature environments?

Yes, it operates within a temperature range of -40°C to 105°C.
