M2024S3A2G45 is listed in the Toggle Switches range at ChipApex. The manufacturer field lists NKK Switches. Its product description is SWITCH TOGGLE SP3T 0.4VA 28V. Review the specifications below when checking this part for your BOM.
Toggle Switches specifications for M2024S3A2G45
- Description：SWITCH TOGGLE SP3T 0.4VA 28V
- Series：M
- Mfr：NKK Switches
- Package：Tray
- Mounting Type：Through Hole, Right Angle, Vertical
- Circuit：SP3T
- Switch Function：On-On-On
- Current Rating (Amps)：0.4VA (AC/DC)
- Voltage Rating - AC：28 V
- Voltage Rating - DC：28 V
- Actuator Type：Standard Round
- Actuator Length：8.28mm
- Illumination：Non-Illuminated
- Illumination Type, Color：-
- Illumination Voltage (Nominal)：-
- Termination Style：PC Pin
- Panel Cutout Dimensions：Circular - 6.50mm Dia
- Bushing Thread：Unthreaded
- Ingress Protection：-
- Features：Jumper needed to achieve triple throw
- Operating Temperature：-30°C ~ 85°C
Toggle Switches datasheet and documents for M2024S3A2G45
