M252513F

$67.90

Description：MODULE POWER 25A 320VAC SCR CC
Series：-

SKU:ad78f0b03fcb Category: SCRs - Modules Brand: Sensata-Crydom

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MODULE POWER 25A 320VAC SCR CC
Series：-
Mfr：Sensata-Crydom
Package：Bulk
Structure：Bridge, Single Phase - SCRs/Diodes (Layout 1)
Number of SCRs, Diodes：2 SCRs, 2 Diodes
Voltage - Off State：800 V
Current - On State (It (AV)) (Max)：-
Current - On State (It (RMS)) (Max)：-
Current - Non Rep. Surge 50, 60Hz (Itsm)：300A @ 60Hz
Operating Temperature：-
Mounting Type：Chassis Mount
Package / Case：Module
Voltage - Gate Trigger (Vgt) (Max)：2.5 V
Current - Gate Trigger (Igt) (Max)：50 mA
Current - Hold (Ih) (Max)：75 mA
Grade：-
Qualification：-

Download product information

M252513F

Overview

The M252513F is a single-phase SCR/diode bridge module manufactured by Sensata-Crydom. It features a chassis mount configuration with an off-state voltage rating of 800 V. The component integrates two SCRs and two diodes within a single module package. This product is designated as obsolete and is not recommended for new designs.

Feature Summary

Single-phase bridge rectifier structure combining SCRs and diodes
Chassis or base mounting design for industrial integration

Applications

Industrial power control systems
Thyristor-based rectification circuits
High-power switching applications

Procurement Notes

This component has been officially discontinued by the manufacturer. Procurement is restricted to existing stock from third-party distributors. Verify part authenticity and storage conditions carefully, as availability is limited and supply chain stability cannot be guaranteed for obsolete items.

Selection Notes

Engineers should avoid selecting this part for new projects due to its obsolete status. Consider alternative components from the same manufacturer that offer current production support and longer lifecycle availability to ensure long-term maintenance and supply continuity.

Part Context

The M252513F belongs to the Crydom line of discrete semiconductor modules. It serves as a thyristor-based solution for AC power control. The module format allows for efficient thermal management in high-current applications requiring robust phase-angle control capabilities.

Replacement Considerations

Public confirmed substitute: VS-P105W (Vishay General Semiconductor). Note that cross-manufacturer replacements require verification of electrical parameters and mechanical fit.
