M254012FV

$85.30

Description：MODULE POWER 40A 600V SCR CC
Series：-

SKU:56a73ed020e4 Category: SCRs - Modules Brand: Sensata-Crydom

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MODULE POWER 40A 600V SCR CC
Series：-
Mfr：Sensata-Crydom
Package：Bulk
Structure：Bridge, Single Phase - SCRs/Diodes (Layout 1)
Number of SCRs, Diodes：2 SCRs, 2 Diodes
Voltage - Off State：600 V
Current - On State (It (AV)) (Max)：-
Current - On State (It (RMS)) (Max)：-
Current - Non Rep. Surge 50, 60Hz (Itsm)：400A @ 60Hz
Operating Temperature：-
Mounting Type：Chassis Mount
Package / Case：Module
Voltage - Gate Trigger (Vgt) (Max)：2.5 V
Current - Gate Trigger (Igt) (Max)：50 mA
Current - Hold (Ih) (Max)：75 mA
Grade：-
Qualification：-

Download product information

M254012FV

Overview

The M254012FV is a silicon SCR-Diode module from the Crydom PGFM series, rated for 40A and 600V. It utilizes screw mount installation and operates within a temperature range of -40°C to +125°C. The component weighs 57.6g and is packaged individually.

Feature Summary

Integrates an SCR and diode in a single discrete semiconductor package
Designed for high-power industrial applications requiring robust thermal management
Utilizes screw mount terminals for secure mechanical attachment

Applications

Industrial motor control systems
Power supply rectification circuits
High-current switching applications

Procurement Notes

Verify the specific suffix against official Sensata-Crydom documentation to confirm exact electrical characteristics and pinout configuration. Ensure compatibility with existing thermal interface materials and mounting hardware specifications before integration into final assemblies.

Selection Notes

Select this module when a combined SCR and diode solution is required for high-current handling. Consider the 600V reverse voltage rating and 40A continuous current capacity against circuit demands. Verify that the screw mount style aligns with the available board space and thermal dissipation requirements of the design.

Part Context

This component belongs to the Crydom PGFM series of discrete semiconductor modules manufactured by Sensata-Crydom. The series focuses on providing reliable power switching solutions for demanding industrial environments, combining multiple semiconductor functions into compact, rugged packages suitable for heavy-duty operation.

Replacement Considerations

Consult official Sensata-Crydom cross-reference guides for verified substitutes. Ensure any replacement matches the 40A current rating, 600V voltage rating, and PGFM series form factor to maintain system performance and safety compliance.
