M30621FCPGP#U9C

Microcontrollers Overview

The M30621FCPGP#U9C is a 16-bit microcontroller based on the M16C/60 core, manufactured by Renesas Electronics Corporation. It features 128 KB of program memory and 10 KB of RAM within an 80-pin QFP package. The device supports a maximum clock frequency of 24 MHz and includes 11 channels of 16-bit timers, 26 channels of 10-bit ADCs, and 2 channels of 8-bit DACs. It operates with a data bus width of 16 bits and complies with EU RoHS and China RoHS standards.

Microcontrollers Feature Summary

• Integrates the M16C/60 16-bit CPU core for efficient processing
• Includes extensive analog peripherals with multiple ADC and DAC channels
• Offers high-resolution timing capabilities via numerous 16-bit timer channels

Microcontrollers Applications

• Industrial control systems requiring robust 16-bit processing
• Automotive applications utilizing the M16C/60 architecture
• General-purpose embedded systems needing integrated analog-to-digital conversion

Microcontrollers Procurement Notes

Verify the specific suffix #U9C against official Renesas documentation to confirm compliance status and package variant. Ensure the ordering information matches the exact pin count and memory configuration required for your design. Cross-reference the datasheet revision to guarantee compatibility with your intended firmware environment.

Microcontrollers Selection Notes

Select this component when a 16-bit architecture with significant onboard memory and rich peripheral sets is required. The M16C/60 core provides a balance of performance and power efficiency suitable for complex control tasks. Consider the 80-pin QFP package constraints and thermal requirements during PCB layout planning.

Microcontrollers Part Context

This part belongs to the Renesas M16C series, specifically the M16C/60 family. These microcontrollers are designed for applications demanding high reliability and advanced peripheral integration. The series is widely used in automotive and industrial sectors where long-term availability and robust performance are critical.

Microcontrollers Replacement Considerations

Consult Renesas official substitution guides for compatible alternatives. Verify pinout compatibility and software register mapping before replacing existing components in production designs.
