Overview

The M3933/25-62N is a fixed RF attenuator module manufactured by Cinch Connectivity Solutions Midwest Microwave. It provides a nominal attenuation value of 2dB across a frequency range of 0 Hz to 12.4 GHz. The component utilizes SMA connectors and is designed as an in-line single-row module. It complies with the MIL-DTL-M3933 military specification, indicating suitability for defense and aerospace applications requiring high reliability.

Feature Summary

• Complies with MIL-DTL-M3933 military specifications for rugged performance
• Provides precise 2dB signal attenuation for RF circuit management
• Operates effectively from DC up to 12.4 GHz frequency range
• Features SMA connector interface for standard integration

Applications

• Military communication systems
• Aerospace electronic testing equipment
• Defense radar signal conditioning
• High-reliability RF measurement setups

Procurement Notes

Verify that the specific suffix 'N' corresponds to the required material or plating configuration as defined in the official datasheet, as ordering suffixes may indicate variations in construction or certification. Confirm compliance with current export control classifications (EAR99) and ensure the non-RoHS status aligns with project regulatory requirements before finalizing procurement orders.

Selection Notes

Select this model when a fixed 2dB attenuation is required within the 12.4 GHz bandwidth. Ensure the system impedance matches the component's design, typically 50 Ohms for this series. Consider the SMA connector type for compatibility with existing test fixtures or cable assemblies. Verify power handling capabilities against peak signal levels to prevent damage during operation.

Part Context

This part belongs to the M3933/25 series of fixed attenuators produced by Midwest Microwave, a division of Cinch Connectivity Solutions. The series offers various attenuation values while maintaining consistent form factors and electrical characteristics suitable for demanding environments. These components are engineered to meet strict military standards for durability and signal integrity.

Replacement Considerations

Direct substitutes include other M3933/25 series variants with identical attenuation values but different connector genders or plating options, such as M3933/25-62S. Cross-reference pinouts and mechanical dimensions to ensure physical compatibility. Verify that alternative parts maintain the same MIL-DTL-M3933 qualification level for equivalent performance.
