M50100SB1000

$103.29

Description：BRIDGE RECT 1P 1KV 100A MODULE
Series：-

SKU:93bc7fd034c7 Category: Bridge Rectifiers Brand: Sensata-Crydom

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：BRIDGE RECT 1P 1KV 100A MODULE
Series：-
Mfr：Sensata-Crydom
Package：Bulk
Diode Type：Single Phase
Technology：Standard
Voltage - Peak Reverse (Max)：1 kV
Current - Average Rectified (Io)：100 A
Voltage - Forward (Vf) (Max) @ If：1.2 V @ 100 A
Current - Reverse Leakage @ Vr：-
Operating Temperature：-40°C ~ 125°C (TJ)
Mounting Type：Chassis Mount
Package / Case：Module
Supplier Device Package：Module
Grade：-
Qualification：-

Download product information

M50100SB1000

Overview

The M50100SB1000 is a silicon single-phase bridge rectifier module manufactured by Sensata-Crydom under the M50 Diode series. It features a screw mount installation style and operates within a temperature range of -40°C to +125°C. The device has a peak reverse voltage (Vr) of 1 kV and a forward voltage (Vf) of 1.2 V. The unit weighs 106 g and is packaged individually.

Feature Summary

Single-phase bridge rectifier configuration
Screw mount base installation
Silicon diode technology

Applications

Industrial power supplies
Motor drive circuits
Welding equipment

Procurement Notes

Verify the manufacturer part number against official Sensata-Crydom documentation to ensure authenticity. Confirm that the specific revision matches project requirements, as component specifications may evolve. Check for RoHS compliance status in the latest datasheet before finalizing procurement orders.

Selection Notes

Select this module when a 1 kV rating and 100 A current capacity are required for single-phase applications. Ensure the mounting hardware supports the screw mount style and thermal management meets the -40°C to +125°C operating range. Compare Vf characteristics with alternative modules if conduction loss is a critical design constraint.

Part Context

This component belongs to the M50 Diode series from Sensata-Crydom, designed for high-power switching applications. The series offers various voltage and current ratings within a standardized mechanical footprint, facilitating modular design in industrial electronics and power conversion systems.

Replacement Considerations

Direct substitutes include other M50 series variants such as M50100SB400 or M50100SB800 for lower voltage needs, or M5060SB1000 for reduced current capacity. Verify pinout compatibility and thermal resistance values before substitution.
