M52-040023V2545 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is CONN HEADER VERT 25POS 1.27MM. Review the specifications below when checking this part for your BOM.
Headers, Male Pins specifications for M52-040023V2545
- Description：CONN HEADER VERT 25POS 1.27MM
- Series：Archer M52
- Mfr：Harwin Inc.
- Package：Bulk
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.050" (1.27mm)
- Number of Positions：25
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Board
- Shrouding：Unshrouded
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.157" (4.00mm)
- Contact Length - Post：0.091" (2.30mm)
- Overall Contact Length：0.346" (8.80mm)
- Insulation Height：0.098" (2.50mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：Flash
- Contact Finish - Post：-
- Contact Material：Brass
- Insulation Material：Polyamide (PA6T), Nylon 6T
- Features：-
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：1A
- Voltage Rating：-
Headers, Male Pins datasheet and documents for M52-040023V2545
Headers, Male Pins Overview
The Harwin M52-040023V2545 is a single-row pin header from the ARCHER series, featuring a 1.27 mm pitch and 25 positions. Designed for vertical through-hole mounting, it utilizes gold-plated brass contacts with a black nylon housing. The component supports a maximum current of 1 A and operates within a temperature range of -40°C to +105°C. It has a voltage rating of 500 V and includes solder pin termination.
Headers, Male Pins Feature Summary
- Single in-line (SIL) unshrouded design for compact board-to-board connections
- Gold-plated brass contacts ensure reliable signal transmission
- Vertical straight orientation facilitates standard PCB integration
Headers, Male Pins Applications
- Board-to-board interconnects
- General electronic circuit assemblies
- Industrial control systems
Headers, Male Pins Procurement Notes
Verify the specific part number against official Harwin documentation to confirm compatibility with required PCB layouts and mating connectors. Ensure that the through-hole tail dimensions align with the target printed circuit board specifications before finalizing procurement decisions.
Headers, Male Pins Selection Notes
Select this component when a single-row, vertical pin header with a 1.27 mm pitch is required. Consider the 1 A current rating and -40°C to +105°C operating temperature range to ensure suitability for the intended environmental conditions and electrical loads.
Headers, Male Pins Part Context
This connector belongs to the Harwin ARCHER M52 series, which offers various configurations including different row counts and contact numbers. The M52-040023V2545 specifically represents a 25-position variant designed for high-density applications requiring robust mechanical and electrical performance.
Headers, Male Pins Replacement Considerations
Consult official Harwin documentation for confirmed substitute part numbers within the ARCHER M52 series or compatible families. Verify dimensional and electrical equivalence before considering alternative sources.
