M63002JUFCC 19.641600

Overview

The M63002JUFCC 19.641600 is a TCXO CMOS clock oscillator manufactured by MtronPTI, operating at a nominal frequency of 19.6416 MHz. It utilizes the QiK Chip technology within a 5x7 mm surface-mount ceramic package featuring six leadless terminals. The device supports a supply voltage of 3.3 V and operates across an industrial temperature range from -40°C to +85°C. Designed for superior jitter performance comparable to SAW-based oscillators, it includes enable/disable functionality and exhibits low phase noise characteristics suitable for high-speed digital applications.

Feature Summary

• TCXO/TCVCXO architecture utilizing QiK Chip technology for enhanced stability
• CMOS output interface with enable/disable control function
• Leadless ceramic surface-mount packaging for compact integration

Applications

• Wireless base stations
• WLAN systems
• Gigabit Ethernet interfaces
• Avionic flight controls
• Military communications equipment

Procurement Notes

Verify the specific suffix and frequency code against official MtronPTI documentation to ensure exact part matching. Confirm RoHS compliance status and lead-free certification requirements prior to ordering. Check for any recent design changes or obsolescence notices on the manufacturer website. Ensure compatibility with the target system's voltage levels and thermal constraints.

Selection Notes

Select this component when a stable CMOS clock source is required in a small form factor. The QiK Chip technology offers jitter performance similar to SAW resonators without their mechanical fragility. Consider the 5x7 mm footprint for space-constrained PCB layouts. Verify that the 3.3V supply voltage aligns with the system power rails and that the -40°C to +85°C range meets environmental demands.

Part Context

This model belongs to the M630x Series QiK Chip family, which integrates TCXO and TCVCXO capabilities into a compact ceramic package. The series supports various output types including LVPECL, LVDS, CML, and CMOS, with frequencies ranging from 50 MHz to 1.4 GHz. The M63002 variant specifically denotes a CMOS output configuration within this broader lineup.

Replacement Considerations

Direct substitutes within the same QiK Chip family include other M63002 variants with different output codes or frequency specifications. Cross-reference part numbers such as M63002HSVCC050.000000MHZ for similar CMOS configurations. Verify pinout compatibility and electrical parameters before substituting with generic TCXOs.
