M80-4002601

Headers, Receptacles, Female Sockets Overview

The M80-4002601 is a Datamate J-Tek series receptacle connector manufactured by Harwin Inc. It features a 26-position configuration with a 0.079-inch (2.00mm) mating pitch. Designed for through-hole PCB mounting, it utilizes gold-plated contacts to ensure reliable signal transmission. The component supports board-to-board or cable applications and operates within a temperature range of -55°C to 125°C.

Headers, Receptacles, Female Sockets Feature Summary

• High-reliability four-finger beryllium copper contact technology ensures connection integrity without loss.
• Datamate J-Tek series design provides robust performance for demanding industrial environments.
• Gold-plated contacts offer superior corrosion resistance and stable electrical conductivity.

Headers, Receptacles, Female Sockets Applications

• Automotive electronics systems
• General industrial control equipment
• Military and defense applications

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix and manufacturing date code upon procurement. Confirm that the component status aligns with current project requirements, as availability may vary. Ensure compatibility with mating headers from the same Datamate J-Tek family to guarantee proper mechanical fit and electrical performance.

Headers, Receptacles, Female Sockets Selection Notes

Select this model when a 26-position female socket is required for high-density interconnects. Consider the through-hole mounting style and 2.00mm pitch constraints. Evaluate the operating temperature range and voltage ratings against system specifications to ensure compliance with environmental and electrical demands.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Datamate J-Tek family, known for its compact size and high reliability. It serves as a female receptacle counterpart to male headers in the M80 series ecosystem. The design emphasizes durability and consistent performance across various harsh operating conditions.

Headers, Receptacles, Female Sockets Replacement Considerations

M80-4001201 is listed as a parameter-equivalent alternative. Verify pin count and physical dimensions before substitution. Ensure mating components are compatible with the replacement part number to maintain system integrity.
