M80-4011242

Headers, Receptacles, Female Sockets Overview

The M80-4011242 is a Harwin Datamate J-Tek board connector, specifically a female socket with a straight orientation and solder tail termination. It features a 2-row configuration with 6+6 positions (12 total) and a 2.00mm pitch. The housing is constructed from black glass-filled polyphenylene sulfide (PPS), rated UL94 V-0. Contacts are beryllium copper with gold plating on the mating interface and tin on the solder tails. It supports a voltage rating of 120V and operates within a temperature range of -55°C to +125°C.

Headers, Receptacles, Female Sockets Feature Summary

• Locking mechanism ensures secure connection stability during operation.
• Gold-plated contacts provide reliable signal transmission and corrosion resistance.
• High-temperature resistant PPS insulator supports demanding thermal environments.

Headers, Receptacles, Female Sockets Applications

• Industrial control systems
• Automotive electronics
• Military and aerospace equipment

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix codes against the official Harwin datasheet to confirm contact length, locking style, and plating specifications. Ensure the selected variant matches the required stacking height and PCB mounting constraints for the target application design.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a compact, high-density board-to-board or cable-to-board connection is required. The 2.00mm pitch allows for dense routing, while the locking feature provides mechanical security in vibration-prone environments compared to non-locking variants.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Harwin Datamate J-Tek series, known for its modular design and robust performance in harsh conditions. The M80-4011242 represents a standard female socket configuration within this family, offering versatility for various interconnect needs.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes must match the 2-row, 12-position, 2.00mm pitch specification. Verify that alternative connectors offer compatible locking mechanisms and similar electrical ratings if cross-referencing with other manufacturers' products.

Headers, Receptacles, Female Sockets FAQ

What is the contact material used in this connector?

The contacts are made of beryllium copper to ensure durability and spring properties.

Is this connector suitable for high-vibration environments?

Yes, the integrated locking mechanism helps maintain connection integrity under vibration.
