M80-4031442

Headers, Receptacles, Female Sockets Overview

The Harwin M80-4031442 is a Datamate J-Tek board-to-board receptacle featuring 14 positions arranged in two rows. It utilizes a 2.00 mm pitch with vertical through-hole mounting for secure PCB integration. The connector employs male pin contacts made of phosphor bronze, finished with gold plating to ensure reliable signal transmission. Constructed from black polyphenylene sulfide (PPS) insulation reinforced with glass fiber, it meets UL94 V-0 flammability standards. Designed for robust performance across a wide temperature range of -55°C to +125°C, this component supports applications requiring high-density interconnects.

Headers, Receptacles, Female Sockets Feature Summary

• Features a shrouded design with integrated keying slots and mounting flanges for precise alignment and secure panel installation.
• Utilizes gold-plated phosphor bronze contacts to provide durable electrical connections resistant to corrosion.
• Constructed from glass-filled PPS insulation offering high thermal stability and compliance with UL94 V-0 safety ratings.

Headers, Receptacles, Female Sockets Applications

• Automotive electronic control units
• Industrial instrumentation systems
• Military communication equipment

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to confirm exact contact configuration and hardware inclusion. Ensure compatibility with mating plugs within the Datamate J-Tek series. Confirm that the selected variant matches the required current rating and voltage specifications for the target application environment before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a vertical, through-hole male header is required for high-density board stacking. The 2.00 mm pitch allows for compact circuit board layouts while maintaining adequate spacing. Consider the integrated mounting flange for applications needing rigid mechanical support. Ensure the mating partner is a compatible female socket from the same Datamate J-Tek family to guarantee proper engagement and electrical continuity.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Datamate J-Tek series by Harwin Inc., designed for demanding environments. The series offers various configurations including surface mount and right-angle options. The M80-4031442 specifically addresses needs for vertical board-to-board connections with robust mechanical locking features, distinguishing it from standard unshrouded headers.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible substitutes include other Harwin Datamate J-Tek male headers with identical 14-position, 2-row, 2.00 mm pitch specifications. Verify that alternative parts maintain the same through-hole mounting style and gold-plated contact finish to ensure interchangeability without redesigning the PCB footprint or mating interface.

Headers, Receptacles, Female Sockets FAQ

What is the contact material used in the M80-4031442?

The contacts are manufactured from phosphor bronze and feature a gold plating finish.

Does this connector include mounting hardware?

Yes, the product description indicates it comes with 101 hardware components for secure installation.
