M80-4051605

Headers, Receptacles, Female Sockets Overview

The Harwin M80-4051605 is a 16-position female receptacle connector from the Datamate J-Tek series. It features a 2.00mm (0.079 inch) pitch with two rows of contacts. Designed for through-hole mounting, it utilizes crimp termination for discrete wire connections. The contacts are gold-plated to ensure reliable signal transmission and corrosion resistance.

Headers, Receptacles, Female Sockets Feature Summary

• Datamate J-Tek series modular design
• Crimp termination for flexible wiring
• Gold-plated contact surfaces

Headers, Receptacles, Female Sockets Applications

• Industrial control systems
• Test and measurement equipment
• Automotive electronics

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix codes against the official datasheet to confirm pin count and orientation. Ensure compatibility with mating male connectors within the same Datamate J-Tek family. Confirm that the crimp tooling matches the specified wire gauge requirements for proper termination integrity.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a robust, high-density interconnect solution is required for panel or cable applications. The crimp termination method offers flexibility in assembly compared to soldered options. Consider the mechanical locking features provided by the series for secure connection stability in vibrating environments.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Datamate J-Tek line, known for its compact size and high reliability. It serves as a key interconnect element in complex electronic assemblies where space constraints and signal integrity are critical factors for system performance.

Headers, Receptacles, Female Sockets Replacement Considerations

M80-4C11605FC is listed as a parameter-equivalent substitute. Verify electrical and mechanical specifications before substitution.
