M80-4061001

Headers, Receptacles, Female Sockets Overview

The M80-4061001 is a male, double-row, vertical printed circuit board connector from the Harwin Datamate J-Tek series. It features a 2.00mm (0.079 inch) mating pitch and utilizes four-finger beryllium copper contact technology for high reliability. The connector is designed with polarized mouldings and fully shrouded contacts to ensure correct mating orientation and protection. It employs reverse fix hex socket jackscrews for secure locking. The housing is constructed from black glass-filled polyphenylene sulfide (PPS), rated UL94 V-0, supporting an operating temperature range of -55°C to +125°C.

Headers, Receptacles, Female Sockets Feature Summary

• Four-finger beryllium copper contact technology ensures connection integrity without loss
• Polarized mouldings and fully shrouded contacts prevent incorrect mating
• Reverse fix hex socket jackscrews provide secure mechanical locking

Headers, Receptacles, Female Sockets Applications

• High-reliability automotive electronics
• Industrial control systems
• Military and aerospace equipment

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific pin count and current rating requirements against the official datasheet before procurement. Confirm that the reverse fix locking mechanism aligns with the assembly design. Check for RoHS3 compliance status as per the latest manufacturer documentation. Ensure compatibility with the corresponding female receptacle connectors within the same Datamate J-Tek family.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when high vibration resistance and reliable signal transmission are critical. The four-finger contact design offers superior retention force compared to standard two-finger contacts. Consider the vertical mounting style and PCB tail termination method for space-constrained applications requiring robust board-to-board or cable connections.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Datamate J-Tek family, known for its high-density interconnect capabilities. The M80-4061001 specifically addresses applications requiring durable, shielded, and locked connections in harsh environments. It complements the broader M80 series portfolio by offering specialized locking and polarization features.

Headers, Receptacles, Female Sockets Replacement Considerations

No direct public substitute part numbers are confirmed for this specific configuration. Evaluate other Datamate J-Tek variants with similar pitch and row counts if exact matches are unavailable. Verify mechanical dimensions and electrical ratings carefully when considering alternative suppliers.
