M80-4101842

Headers, Receptacles, Female Sockets Overview

The M80-4101842 is a board-to-board connector from the Datamate J-Tek series, manufactured by Harwin Inc. It features a female receptacle configuration with 18 positions arranged in a dual in-line (DIL) format. The connector utilizes a 2.00mm pitch and is designed for vertical through-hole mounting on printed circuit boards. Contact materials consist of beryllium copper with gold plating on the mating interface to ensure reliable signal transmission. The housing is constructed from black polyphenylene sulfide (PPS), providing high thermal stability and mechanical strength.

Headers, Receptacles, Female Sockets Feature Summary

• Dual in-line female receptacle design for secure board-to-board interconnection
• Gold-plated beryllium copper contacts ensuring low resistance and durability
• Polyphenylene sulfide insulator offering high heat resistance and UL94 V-0 flammability rating
• Vertical through-hole termination style for robust PCB attachment

Headers, Receptacles, Female Sockets Applications

• Industrial control systems requiring reliable signal connectivity
• Automotive electronic modules needing durable interconnects
• Military equipment demanding high-performance board connections
• General purpose electronics utilizing standard DIL form factors

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific part number against official Harwin documentation to confirm pin count and contact configuration. Ensure compatibility with mating male pins regarding pitch and locking mechanisms. Check for RoHS compliance status if required by project specifications. Confirm that the vertical orientation matches the assembly layout requirements before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a 18-position female connector with a 2.00mm pitch is required for vertical mounting. Consider the gold plating for applications involving frequent mating cycles or corrosive environments. Evaluate the operating temperature range of -55°C to +125°C against system thermal profiles. Ensure sufficient panel space accommodates the dual-row footprint and locking hardware dimensions.

Headers, Receptacles, Female Sockets Part Context

This connector belongs to the Datamate J-Tek family, known for high-density interconnect solutions. The M80 series offers various configurations including straight and right-angle options. This specific model provides a standardized solution for connecting daughterboards to motherboards in compact electronic assemblies.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible mating parts include male headers such as M80-5101842. Verify dimensional compatibility and electrical ratings before substituting with alternative manufacturers' products. Ensure locking mechanisms align with existing chassis or panel cutouts.
