M80-4103442

Headers, Receptacles, Female Sockets Overview

The Harwin M80-4103442 is a Datamate J-Tek socket assembly featuring 34 positions arranged in two rows. It utilizes a 2 mm pitch and is designed for straight through-hole mounting with solder pin termination. The contacts are gold-plated beryllium copper, rated for 3 A current. Operating temperature ranges from -55°C to +125°C. The housing is black polyphenylene sulfide (PPS) with UL 94 V-0 flammability rating.

Headers, Receptacles, Female Sockets Feature Summary

• Datamate J-Tek series interconnect system
• Fully shrouded female socket design
• Gold-plated contact surfaces for reliability
• Straight through-hole PCB mounting style

Headers, Receptacles, Female Sockets Applications

• Industrial control systems
• Test and measurement equipment
• Automotive electronics
• Telecommunications infrastructure

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix configuration against official Harwin documentation to ensure correct mating compatibility and mechanical features. Confirm RoHS compliance status and material specifications prior to integration. Cross-reference datasheet revisions to validate current manufacturing status and environmental certifications.

Headers, Receptacles, Female Sockets Selection Notes

Select this component for applications requiring high-density connections with robust mechanical locking. The 2 mm pitch allows compact board layouts while maintaining reliable signal integrity. Ensure mating header selection matches the J-Tek series specifications for proper engagement and retention force.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Datamate J-Tek family, known for high-reliability interconnect solutions. The series offers various configurations including power and signal variants. The M80-4103442 specifically addresses needs for multi-position female receptacles in space-constrained environments.

Headers, Receptacles, Female Sockets Replacement Considerations

No direct public substitute part numbers are confirmed for this specific model. Evaluate compatible Datamate J-Tek series alternatives based on position count and pitch requirements. Verify mechanical and electrical compatibility before considering any cross-reference options.
