M80-4111042

Headers, Receptacles, Female Sockets Overview

The Harwin M80-4111042 is a 10-position female receptacle connector from the Datamate J-Tek series. It features a 2.00mm pitch and is designed for through-hole solder termination. The unit utilizes beryllium copper contacts with gold plating on the mating interface and tin on the tail. Constructed with black glass-filled polyphenylene sulfide insulation, it supports board-to-board or cable interconnect applications. Rated for 120V, it operates within a temperature range of -55°C to 125°C.

Headers, Receptacles, Female Sockets Feature Summary

• Secure locking mechanism ensures robust connection integrity under vibration and shock.
• High-reliability four-finger beryllium copper contacts maintain performance in harsh environments.
• Fully shrouded polarized housing prevents misalignment during mating.
• Compatible with standard screw-lock fastening options for secure assembly.

Headers, Receptacles, Female Sockets Applications

• Automotive electronics systems
• Military and defense equipment
• General industrial control boards

Headers, Receptacles, Female Sockets Procurement Notes

Verify that the specific part number matches the required contact configuration and termination style. Confirm compliance with RoHS directives and material safety data sheets before integration. Ensure storage conditions preserve the integrity of the gold-plated contacts. Cross-reference mating components to guarantee mechanical compatibility with the locking system.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when high reliability and secure locking are critical for board-to-board connections. The Datamate J-Tek series offers superior durability compared to standard connectors. Consider the operating temperature range and voltage ratings against application requirements. Evaluate space constraints regarding the insulator height and stacking dimensions.

Headers, Receptacles, Female Sockets Part Context

This receptacle belongs to the Harwin Datamate J-Tek family, known for high-performance interconnects. The series is engineered for demanding applications requiring resistance to environmental stressors. It complements male headers and plugs within the same ecosystem. The design emphasizes long-term stability and repeated cycle endurance.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes must match the 2.00mm pitch, 10-position count, and female socket configuration. Verify identical locking mechanisms and shrouding styles for mechanical interchangeability. Ensure compatible mating parts from the same manufacturer series to maintain polarization and alignment.

Headers, Receptacles, Female Sockets FAQ

What is the contact material used in this connector?

The contacts are manufactured from beryllium copper to ensure high conductivity and spring properties.

Is the connector polarized?

Yes, the housing is fully shrouded and polarized to prevent incorrect mating orientation.
