M80-4120642

Headers, Receptacles, Female Sockets Overview

The M80-4120642 is a 6-position female receptacle connector from the Harwin Datamate J-Tek series. It features a 2.00mm (0.079 inch) mating pitch and is designed for surface mount installation. The connector utilizes gold-plated contacts with a polyphenylene sulfide (PPS) insulator, rated for 120V.

Headers, Receptacles, Female Sockets Feature Summary

• Vertical surface mount termination for compact PCB integration
• Gold-plated contacts ensure reliable signal transmission
• Polyphenylene sulfide housing provides thermal stability

Headers, Receptacles, Female Sockets Applications

• Automotive electronics systems
• General industrial equipment
• Military applications

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific datasheet version to confirm exact plating thickness and RoHS compliance status. Ensure the ordering suffix matches the required contact configuration and locking mechanism. Cross-reference the footprint dimensions with the target PCB design to guarantee accurate surface mount alignment during assembly.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile vertical female connector is required for space-constrained designs. It pairs with Datamate J-Tek male headers. Consider the surface mount orientation versus through-hole alternatives based on mechanical stress requirements and manufacturing capabilities of the assembly line.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Datamate J-Tek family, known for high-density interconnects. The M80-4xx series specifically denotes female receptacles within this ecosystem. These connectors are engineered for robust performance in demanding environments, offering a balance of electrical reliability and mechanical durability across various industries.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible substitutes include other Harwin Datamate J-Tek female receptacles with matching 2.00mm pitch and surface mount termination. Verify that alternative parts maintain identical housing dimensions and locking mechanisms to ensure seamless interchangeability without redesigning the host PCB layout.
