M80-4122642

Headers, Receptacles, Female Sockets Overview

The M80-4122642 is a 26-position female receptacle connector from the Harwin Datamate J-Tek series. It features a 2.00mm (0.079 inch) mating pitch and utilizes surface mount termination for PCB integration. The connector employs gold-plated contacts with a thickness of 12.0µin (0.30µm) on the mating interface, ensuring reliable signal transmission. Designed for robust performance, it supports operation within a temperature range of -55°C to +125°C and meets UL94 V-0 flammability standards.

Headers, Receptacles, Female Sockets Feature Summary

• High mechanical resilience with 100G shock, 40G bump, and 10G vibration resistance ratings
• Integrated jackscrews provide secure locking during mating cycles
• Surface mount design facilitates automated PCB assembly processes

Headers, Receptacles, Female Sockets Applications

• Automotive electronic systems
• Military equipment interconnects
• General industrial control units

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix to confirm the presence of integrated jackscrews and exact contact configuration. Ensure compatibility with the mating male header within the same Datamate J-Tek family. Confirm that the surface mount footprint aligns with the target PCB design specifications before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when high-density connections are required alongside significant mechanical stress protection. The surface mount format is suitable for applications demanding compact board profiles. Consider the operating temperature range and environmental exposure requirements to ensure long-term reliability in harsh conditions.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Datamate J-Tek family, known for its modular design and high durability. The series offers various configurations including through-hole and surface mount options. The M80-4122642 specifically addresses needs for secure, high-cycle count connections in space-constrained environments requiring robust physical protection.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct replacement parts include M80-4022642P, though availability may vary. Verify pin count and mounting style compatibility when considering alternative suppliers or updated revisions within the manufacturer's portfolio.
