M80-4211005

Headers, Receptacles, Female Sockets Overview

The Harwin M80-4211005 is a 10-position female board connector from the Datamate J-Tek series. It features a 2.00mm pitch and two rows of contacts. The connector utilizes a through-hole termination method with gold-plated contacts for reliable signal transmission. Designed for vertical panel or board mounting, it incorporates a jack screw locking mechanism to ensure secure connection integrity in demanding environments.

Headers, Receptacles, Female Sockets Feature Summary

• Features a robust jack screw locking system for secure mechanical retention
• Utilizes gold-plated beryllium copper contacts for corrosion resistance
• Supports vertical through-hole installation on printed circuit boards
• Constructed with black glass-filled polyphenylene sulphide insulation

Headers, Receptacles, Female Sockets Applications

• Industrial control systems requiring secure board-to-board connections
• Automotive electronics applications needing vibration-resistant interfaces
• Military equipment utilizing high-reliability interconnect solutions

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to confirm terminal type and contact plating specifications. Ensure compatibility with mating header components within the same Datamate J-Tek series. Confirm that the jack screw locking style matches the assembly requirements. Cross-reference the pin count and row configuration with the target PCB layout design before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a secure, locked interface is required for vertical board mounting. The jack screw mechanism provides superior retention compared to standard latches. Consider the 2.00mm pitch for spacing constraints. Evaluate the through-hole termination for mechanical strength during soldering processes. Ensure the operating temperature range aligns with the application environment.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Datamate J-Tek family, known for high-density interconnects. The M80-421 prefix indicates a female socket variant. The series is widely used in harsh environments due to its rugged construction. It complements male headers and cable assemblies within the same ecosystem to form complete connectivity solutions.

Headers, Receptacles, Female Sockets Replacement Considerations

M80-4201042

Headers, Receptacles, Female Sockets FAQ

What is the locking mechanism for this connector?

It uses a jack screw locking system for secure retention.

What is the contact material used?

The contacts are made of beryllium copper with gold plating.
