M80-4S13042F9

Headers, Receptacles, Female Sockets Overview

The M80-4S13042F9 is a Datamate J-Tek series board connector manufactured by Harwin Inc. It features a double-row female receptacle configuration with ten contacts arranged in a 5+5 layout. Designed for surface mount technology, this straight vertical connector utilizes gold plating on contact areas and tin finish on terminations to ensure reliable electrical performance.

Headers, Receptacles, Female Sockets Feature Summary

• Double-row female receptacle design for high-density interconnects
• Straight vertical surface mount installation style
• Gold-plated contact areas for enhanced conductivity
• Tin-finished solder terminations for secure PCB attachment

Headers, Receptacles, Female Sockets Applications

• High-reliability electronic assemblies requiring robust connections
• Industrial control systems demanding durable interconnects
• Automotive electronics applications needing stable signal transmission

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to confirm exact pin count and termination type. Ensure compatibility with existing PCB footprint designs before procurement. Cross-reference part numbers with authorized distributors to avoid counterfeit components. Confirm RoHS compliance status if required for your specific manufacturing standards.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a double-row female surface mount connector is required. The straight vertical orientation suits boards where mating connectors align perpendicularly. Gold contacts are preferred for environments requiring low contact resistance and corrosion resistance. Tin terminations facilitate standard reflow soldering processes during assembly.

Headers, Receptacles, Female Sockets Part Context

This connector belongs to the Datamate J-Tek family, known for versatility and durability. The M80 series offers various configurations including through-hole and surface mount options. This specific model provides a compact solution for space-constrained applications while maintaining high reliability standards typical of the Harwin product line.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes must match the double-row female SMT specification. Verify that alternative parts maintain the same 10-contact layout and gold/tin plating combination. Ensure mechanical dimensions and mounting hole patterns are identical to prevent PCB redesign requirements.
