M80-4T10405F1-04-321-00-000

Headers, Receptacles, Female Sockets Overview

The M80-4T10405F1-04-321-00-000 is a Datamate Mix-Tek board connector from Harwin Inc., designed as a female vertical surface-mount header. It features a 2-row configuration with 25 positions (50 total contacts) and utilizes a 2.00mm pitch. The connector employs gold-plated beryllium copper contacts for reliable signal transmission and includes jackscrews, mating flanges, mounting flanges, and polarizing keys for secure assembly. It supports mixed signal and power applications within the Datamate ecosystem.

Headers, Receptacles, Female Sockets Feature Summary

• Vertical surface-mount termination for direct PCB integration
• Integrated jackscrew locking mechanism for vibration resistance
• Polarizing key design ensures correct mating orientation
• Mixed-signal capability supporting combined power and data lines

Headers, Receptacles, Female Sockets Applications

• Automotive electronic control units
• Military avionics systems
• General industrial equipment interfaces

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix to confirm contact plating thickness, insulator color, and terminal style compatibility. Ensure the selected variant matches the required stack height and mounting flange configuration for the target enclosure. Cross-reference the manufacturer's latest datasheet to confirm RoHS compliance status and material specifications before final procurement.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a high-density, vertically mounted female connector is required for surface-mount technology. The 2.00mm pitch allows for compact board layouts while maintaining robust mechanical locking via jackscrews. Consider the mixed-signal nature of the Datamate Mix-Tek series if both power distribution and signal integrity are needed in a single interface solution.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Harwin Datamate Mix-Tek series, which combines standard signal contacts with larger power contacts in a single housing. The series is known for its ruggedness and versatility in harsh environments. The M80-4 prefix indicates a specific housing size and row configuration within the broader Datamate product family.

Headers, Receptacles, Female Sockets Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing mating headers and ensure that any alternative component matches the 2.00mm pitch, vertical SMT profile, and jackscrew locking requirements.
