M80-5000000M1-04-PM1-00-000

Headers, Male Pins Overview

The M80-5000000M1-04-PM1-00-000 is a Datamate Mix-Tek male cable connector manufactured by Harwin. It features four power contacts designed for 18 AWG wire termination. The connector utilizes a crimp termination method and is configured without jackscrews or signal contacts, focusing exclusively on high-current power transmission applications within the Power to the Board system.

Headers, Male Pins Feature Summary

• Datamate Mix-Tek series male cable connector configuration
• Four dedicated power contact positions for current carrying
• Crimp termination interface for reliable wire attachment
• Jack-screw free design for streamlined panel integration

Headers, Male Pins Applications

• Industrial equipment power distribution
• Medical device internal power connections
• Automotive electronics harnessing
• Telecommunications infrastructure power supply

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to ensure correct contact count and termination type. Confirm that the absence of jackscrews aligns with the mechanical mounting requirements of the target application. Cross-reference the 18 AWG wire gauge specification with the intended cable assembly to guarantee proper crimp compatibility and electrical performance standards.

Headers, Male Pins Selection Notes

Select this component when a robust, high-current power connection is required without the need for signal lines or locking screws. Ensure the mating female counterpart matches the Datamate Mix-Tek standard. Validate that the 18 AWG wire size fits the physical constraints of the cable assembly and that the crimp tooling supports the specific contact geometry defined in the manufacturer's documentation.

Headers, Male Pins Part Context

This part belongs to the Datamate Mix-Tek family, which provides mixed signal and power solutions. The M80-5000000 prefix indicates a male cable connector variant. This specific model isolates power functionality, offering a compact and reliable interconnect solution for demanding environments where space is limited and high current capacity is essential for system operation.

Headers, Male Pins Replacement Considerations

Direct substitutes must maintain the Datamate Mix-Tek interface and 4-power-contact configuration. Verify that any alternative part number preserves the 18 AWG wire gauge compatibility and crimp termination style. Ensure mechanical dimensions and mating force characteristics remain consistent to avoid assembly issues.
