M80-5000000M1-10-PM1-00-000

Headers, Male Pins Overview

The Harwin M80-5000000M1-10-PM1-00-000 is a Datamate Mix-Tek male cable connector designed for power-to-board applications. It features ten 18 AWG power contacts and excludes signal pins or jackscrews. The component supports a current rating of 40 A and a voltage rating of 800 V. Constructed with high-reliability four-finger beryllium copper contact technology, it ensures connection integrity without signal loss.

Headers, Male Pins Feature Summary

• Utilizes high-reliability four-finger beryllium copper contact technology to maintain connection integrity
• Designed specifically for power transmission with dedicated power-only contact configuration
• Supports high-voltage and high-current operational requirements

Headers, Male Pins Applications

• Power distribution systems requiring robust cable connections
• Industrial equipment needing high-current power delivery
• Applications demanding reliable power-to-board interfaces

Headers, Male Pins Procurement Notes

Verify the specific part number against official Harwin documentation to confirm the 40 A current and 800 V voltage ratings. Ensure the application environment matches the connector's power specifications. Confirm that the absence of jackscrews aligns with the mechanical mounting requirements of the target assembly.

Headers, Male Pins Selection Notes

Select this component when high-power transmission is required alongside compact cabling. The 18 AWG capacity suits substantial current loads. Verify that the lack of signal contacts meets the system design, as this model is strictly for power. Ensure mating connectors are compatible with the Datamate Mix-Tek series.

Headers, Male Pins Part Context

This part belongs to the Datamate Mix-Tek series by Harwin, specialized in power connectivity. It complements other M80 series components by offering a dedicated power solution. The series is known for its reliability in demanding environments, utilizing advanced contact materials for consistent performance.

Headers, Male Pins Replacement Considerations

Consult official Harwin resources for verified substitute part numbers within the Datamate Mix-Tek family. Ensure any replacement maintains the 40 A current and 800 V voltage ratings. Verify compatibility with existing 18 AWG cables and mating hardware.
