M80-5000000M2-06-PM1-00-000

Headers, Male Pins Overview

The M80-5000000M2-06-PM1-00-000 is a Datamate Mix-Tek male cable connector manufactured by Harwin. It features a 6-position configuration designed for power transmission applications. The connector utilizes a 2 mm pitch and supports up to 18 AWG wire gauge. This specific variant includes no jackscrews and contains no signal contacts, focusing exclusively on high-power connectivity.

Headers, Male Pins Feature Summary

• Datamate Mix-Tek series construction for robust power delivery
• Male pin contact type suitable for cable mounting
• Supports 18 AWG maximum wire gauge for high current capacity

Headers, Male Pins Applications

• Power to board interconnects
• High-power cable assemblies
• Industrial equipment power distribution

Headers, Male Pins Procurement Notes

Verify the exact part number against official Harwin documentation to ensure correct Mix-Tek specifications. Confirm that the absence of jackscrews aligns with mechanical requirements. Check for RoHS compliance status in the latest datasheet before procurement.

Headers, Male Pins Selection Notes

Select this component when high-current power transmission is required without signal lines. Ensure the mating connector matches the Mix-Tek female profile. Verify that the 2 mm pitch fits within the available PCB or cable assembly space constraints.

Headers, Male Pins Part Context

This part belongs to the Datamate Mix-Tek family, specialized for high-power applications. It complements other Mix-Tek variants by offering a simplified design focused solely on power contacts. The series provides reliable connections in demanding industrial environments.

Headers, Male Pins Replacement Considerations

Consult Harwin's official cross-reference list for verified substitutes. Generic connectors may not match the 2 mm pitch or 18 AWG capacity. Ensure any replacement maintains the male pin configuration and Mix-Tek compatibility.
