M80-5000000M3-04-331-00-000

Headers, Male Pins Overview

The M80-5000000M3-04-331-00-000 is a Datamate Mix-Tek male cable connector manufactured by Harwin. It features four positions with a 2.00 mm pitch and utilizes tin-plated contacts. The component supports 18 AWG wire gauges and employs a through-hole termination method. Designed for power-to-board applications, it includes jackscrews for secure mounting.

Headers, Male Pins Feature Summary

• Datamate Mix-Tek series design for high-reliability interconnects
• Male pin configuration with tin plating for corrosion resistance
• Through-hole termination for robust PCB attachment
• Integrated jackscrews for mechanical stability

Headers, Male Pins Applications

• Power distribution in industrial control systems
• High-reliability aerospace wiring harnesses
• Medical device power interfaces
• Automotive electronic module connections

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm contact plating and jack screw inclusion. Ensure the selected variant matches the required wire gauge and termination style. Cross-reference the manufacturer datasheet for precise dimensional tolerances and mating partner compatibility before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this connector when a male power interface with through-hole mounting is required. The tin plating offers cost-effective corrosion protection suitable for general environments. Verify that the 18 AWG capacity meets the current carrying requirements of the application circuit.

Headers, Male Pins Part Context

This part belongs to the Datamate Mix-Tek family, which combines signal and power contacts within a single housing. The M80 series is engineered for harsh environments, offering vibration resistance and secure locking mechanisms via jackscrews, making it distinct from standard signal-only connectors.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Harwin Datamate Mix-Tek male connectors with identical pin counts and termination styles. Ensure any replacement maintains the same 2.00 mm pitch and housing dimensions for panel compatibility.
