M80-5000000M5-08-313-00-000

Headers, Male Pins Overview

The M80-5000000M5-08-313-00-000 is a Datamate Mix-Tek connector from Harwin Inc., designed for power-to-the-board applications. It features a 6-position male configuration with straight, through-board termination. The component utilizes a 2 mm pitch and supports a current rating of 3 A per contact. Constructed with black polyamide insulation and copper alloy contacts, it operates within a temperature range of -55°C to +125°C. The housing meets UL 94 V-0 flammability standards, ensuring reliability in industrial environments.

Headers, Male Pins Feature Summary

• Datamate Mix-Tek hybrid design combining signal and power capabilities
• Straight through-board mounting for secure PCB integration
• High-temperature polyamide insulation for thermal stability

Headers, Male Pins Applications

• Industrial control systems requiring mixed signal/power connections
• Automotive electronics harnesses
• Telecommunications infrastructure equipment

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to confirm pin count and termination style. Ensure compatibility with mating female connectors from the same Datamate series. Check RoHS compliance status directly with the manufacturer before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a straight, through-board male connector is required for mixed-signal applications. The 2 mm pitch allows for dense packaging while maintaining 3 A current capacity. Verify that the operating environment stays within the specified -55°C to +125°C range for optimal performance.

Headers, Male Pins Part Context

This part belongs to the Datamate L-Tek and Mix-Tek families by Harwin, known for high-reliability interconnects. The Mix-Tek series specifically addresses needs for combined signal and power transmission in compact spaces. It complements other Datamate variants like J-Tek and S-Tek for complete system solutions.

Headers, Male Pins Replacement Considerations

No direct public substitute part numbers are confirmed for this specific model. Cross-reference only with other Harwin Datamate Mix-Tek or L-Tek series components sharing identical pitch, position count, and termination type to ensure mechanical and electrical compatibility.
