M80-5000200M2-01-331-01-331

Headers, Male Pins Overview

The Harwin M80-5000200M2-01-331-01-331 is a Datamate Mix-Tek female vertical throughboard connector. It features a 4-position single in-line (SIL) configuration with a 2 mm pitch. The contacts are gold-plated beryllium copper sockets designed for reliable power transmission. The housing is constructed from black polyphenylene sulfide (PPS), providing thermal stability and mechanical strength. This component supports surface or through-hole mounting styles, ensuring secure integration into high-density electronic assemblies requiring robust power connections.

Headers, Male Pins Feature Summary

• Datamate Mix-Tek series compatibility for mixed signal and power applications
• Gold-plated beryllium copper socket contacts for enhanced conductivity
• Vertical orientation with single in-line (SIL) 4-position layout
• Polyphenylene sulfide (PPS) insulator for high thermal resistance

Headers, Male Pins Applications

• Industrial control systems
• Power distribution modules
• Telecommunications equipment
• Automotive electronics

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm contact plating thickness and housing color variations. Ensure the selected variant matches the required current rating and voltage specifications for the target application. Cross-reference the datasheet for RoHS compliance status and material declarations before finalizing procurement orders to meet regulatory standards.

Headers, Male Pins Selection Notes

Select this connector when a compact, vertical power interface is required. The 2 mm pitch allows for high pin density within limited board space. Verify that the mating cable or header components belong to the same Datamate Mix-Tek family to ensure proper alignment and locking mechanisms. Consider the operating temperature range and insulation resistance requirements during the design phase.

Headers, Male Pins Part Context

This part belongs to the Harwin Datamate Mix-Tek family, which combines power and signal contacts in a single connector system. The series is known for its versatility in handling mixed loads. The M80 prefix indicates the specific product line within the broader Harwin connector portfolio, focusing on high-reliability interconnect solutions for demanding environments.

Headers, Male Pins Replacement Considerations

Direct substitutes may include other Harwin Datamate Mix-Tek female connectors with identical 4-position SIL configurations and 2 mm pitch. Verify mechanical dimensions and contact material compatibility before substitution. Generic alternatives may lack the specific locking features or thermal performance of the original Datamate design.
