M80-5000200M3-01-331-01-331

Headers, Male Pins Overview

The M80-5000200M3-01-331-01-331 is a Datamate Mix-Tek male header connector manufactured by Harwin. It features a 4-position configuration with gold-plated contacts and black PPS insulation rated UL94 V-0. The component supports a current rating of 20A and a voltage rating of 800VAC/DC. Designed for through-hole mounting, it utilizes solder pin termination to ensure reliable electrical connections in power-to-board applications.

Headers, Male Pins Feature Summary

• Datamate Mix-Tek series compatibility for mixed signal and power integration
• Gold-plated contact surfaces for enhanced conductivity and corrosion resistance
• Black Polyphenylene Sulfide (PPS) housing with UL94 V-0 flammability rating

Headers, Male Pins Applications

• Power distribution modules
• Industrial control systems
• Telecommunications equipment

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to confirm pin count, contact plating, and housing material specifications. Ensure the selected variant matches the required current and voltage ratings for the target application environment. Cross-reference the manufacturer part number with authorized distributors to confirm authenticity and availability status before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this connector when high current capacity up to 20A is required alongside standard Datamate mechanical interfaces. The 4-position layout suits compact power delivery needs. Verify that the through-hole solder termination method aligns with the PCB manufacturing capabilities and that the 800VAC/DC rating exceeds the system's maximum operating voltage requirements.

Headers, Male Pins Part Context

This component belongs to the Datamate Mix-Tek family, designed for versatile interconnect solutions combining power and signal lines. The male header format mates with corresponding female sockets to establish secure board-to-board or cable-to-board connections within electronic assemblies requiring robust power handling.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Harwin Datamate Mix-Tek male headers with identical 4-position layouts and matching termination styles. Verify that alternative parts maintain equivalent 20A current ratings and 800VAC/DC voltage withstand capabilities to ensure functional interchangeability.
