M80-5000605

Headers, Male Pins Overview

The M80-5000605 is a Datamate J-Tek male plug connector designed for vertical through-board mounting. It features a double-row configuration with six contacts arranged in a 3+3 layout. The component utilizes internally threaded jackscrews for secure mating retention. Electrical specifications include a current rating of 2.2A and a voltage rating of 800VAC/DC. Contact finish thickness on posts measures 29.5µin. Insulation color is black, and the unit supports mated stacking heights of 7.3mm or 7.8mm.

Headers, Male Pins Feature Summary

• Double-row male plug design for vertical PCB integration
• Internally threaded jackscrew mechanism for secure locking
• Gold-plated phosphor bronze contacts for reliable conductivity
• Polyphenylene sulfide insulation material for thermal stability

Headers, Male Pins Applications

• Industrial control systems requiring high-reliability power connections
• Test and measurement equipment interfaces
• Automotive electronics harnesses
• Medical device internal wiring
• Telecommunications infrastructure components

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm jack screw inclusion and contact plating details. Ensure compatibility with corresponding socket connectors within the Datamate J-Tek series. Check for RoHS compliance status if required by project specifications. Confirm lead time availability as manufacturing schedules may vary. Validate mechanical dimensions against PCB footprint requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this model when vertical orientation and robust mechanical retention are critical. The 2.2A current rating suits moderate power distribution needs. Consider the 7.3mm or 7.8mm stacking height for enclosure clearance. Verify that the 3+3 contact arrangement meets signal or power pin requirements. Ensure the operating temperature range aligns with environmental conditions.

Headers, Male Pins Part Context

This component belongs to the Harwin Datamate J-Tek family, known for high-density interconnect solutions. The series offers various configurations including mixed signal and power options. The M80-5000605 specifically addresses applications needing durable vertical board-to-board or cable connections. Its design emphasizes ease of assembly and long-term reliability in demanding environments.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Datamate J-Tek male headers with identical pin counts and jack screw features. Verify matching pitch and insulation height for direct replacement. Cross-reference part numbers like M80-5002605 for similar structural attributes but different pin layouts.

Headers, Male Pins FAQ

What is the contact material used in the M80-5000605?

The contacts are made from phosphor bronze with a gold plating finish.

Does this connector include jackscrews?

Yes, the M80-5000605 is fitted with internally threaded jackscrews for secure mating.
